7267-48BL Four (4) Needle High Speed Compound Feed

Lockstitch Sewing Machine for Military Parachutes




Seiko LSWN-48BL 4 needle parachute sewing machine

Your advantages:

1. Lockstitching in 4 rows simultaneously, perfect for quickly and evenly reinforcing areas that require strength, in the manufacturers of parachutes, tents,cover and reflective vests etc.

2. The bottom feed, needle feed and alternating top feed are combined with a high stroke sewing foot to ensure excellent material feeding and easier crossing of transversal seams, even thick ones;

3. The vertical hook with increased bobbin capacity is especially suited for manufacturing with solid sewing threads etc.

4. A safety clutch if fitted as standard to help prevent hook damage or uncontrolled change of hook timing;

5. Direct drive technology offering energy efficiency and eliminating the need for belt replacements. With improved speed control and needle positioning;

6. Puller feeder for sewing heavyweight materials, achieving positive feeding of heavy and difficult materials and creating uniform seams without struggle.

Applications:

Suitable for sewing military parachutes, lightweight tents, tarpaulins, covers, awnings, tents, reflective stripes, sports and camping equipment, life rafts, boat and furniture upholstery, wearing apparel, outdoor clothing, footwear, foundation garments, and other reinforcing areas that require strength. .



Specifications:

Max. Sewing Speed:

1700 rpm

Hook Type:

Double capacity

Min. Sewing Speed :

Stitch by stitch

Stitch type:

301

Needle System:

134-35 Size#110-140

Max. Thread size:

10/3

Stitch Length:

60mm

Bobbin size:

Outside Dia. 26mm, Height 11.2mm

Max. sewing thickness:

10mm

Presser foot alternating::

5mm

Length of arm:

490mm

Recommended motor:

Kinedyne HM-750SH servo motor

Packing size:

1060x600x170MM, 45KGS

Tariff code (HS code):

8452290000
