7246 Narrow Cylinder Bed Compound Walking Foot

Industrial Leather Sewing Machine




Juki DSC-246 industrial sewing machine

Your advantages:

1. The small cylinder bed has an outstanding ability to sew small curves smoothly, ideal for sewing into tight areas and insides of leather bags, shoes and other small articles;

2. The compound walking-foot (alternating presser feet + needle feed + feed dog) provides optimal feed efficiency by feeding heavy materials smoothly and firmly;

3. The double-capacity hook accommodates thread twice as long as that for a standard hook. It also reduces the frequency of bobbin thread replacement, thereby enabling the operator to smoothly conduct sewing with a higher degree of efficiency;

4. The open sewing area around the cylinder arm makes it easy to turn and maneuver the product being sewn without having to fold or roll the product;

5. This heavy duty leather sewing machine is particularly user-friendly due to the Kinedyne HM-750SH low speed servo motor that allows slow, controlled stitching. It makes sewing detailed work much easier;

6. The automatic needle UP and DOWN needle positioning synchronizer makes it easy to control the machine, even when sewing complicated seams.

Applications:

bags, shoes, chaps, jackets, vests, belts, upholstery, saddlebags, boots as well as automobile and boat covers, sails, tents, awnings, luggage, orthopaedic appliances, sports equipment and more.



Specifications:

Max. Sewing Speed:

1700 rpm

Hook Type:

Double capacity

Min. Sewing Speed :

Stitch by stitch

Stitch type:

301

Needle System:

134-35 Size#110-140

Max. Thread size:

10/3

Stitch Length:

60mm

Bobbin size:

Outside Dia. 26mm, Height 11.2mm

Max. sewing thickness:

10mm

Presser foot alternating::

5mm

Length of arm:

490mm

Recommended motor:

Kinedyne HM-750SH servo motor

Packing size:

1060x600x170MM, 45KGS

Tariff code (HS code):

8452290000


Need to expand your production and maximize profits? Contact us at info@automatic-sewing.com
